Find a huge range of Slide Potentiometers at element14 Vietnam. We stock a large selection of Slide Potentiometers, including new and most popular products from the world's top manufacturers including: Bourns, Panasonic, Alps Alpine, TT Electronics / Bi Technologies & ETI Systems

Mã Số Linh Kiện Nhà Sản Xuất	Mã Đơn Hàng	Nhà Sản Xuất / Mô Tả	Giá cho	Giá	Slide Potentiometer Type	Track Resistance	Resistance Tolerance	Power Rating	Track Taper	Potentiometer Mounting	Length of Travel	Lever Length	Temperature Coefficient	Resistor Technology	Potentiometer Terminals	Product Range	Product Length	Product Width	Product Height	Operating Temperature Min	Operating Temperature Max

404R5KL1.0	1330291 Bảng Tính RoHS	TT ELECTRONICS / BI TECHNOLOGIES LINEAR MOTION POTENTIOMETER 5KOHM 10%	Each	1+US$29.810 2+US$28.930 3+US$28.050 5+US$27.170 10+US$24.460 Thêm định giá…	-	5kohm	± 10%	250mW	-	-	12.7mm	20.6mm	-800ppm/°C	Conductive Plastic	Turret	404 Series	26.92mm	12.7mm	8.51mm	-55°C	125°C
404R1KL1.0	1305319 Bảng Tính RoHS	TT ELECTRONICS / BI TECHNOLOGIES LINEAR MOTION POTENTIOMETER 1KOHM 10%	Each	1+US$29.240 2+US$27.790 3+US$26.340 5+US$24.880 10+US$24.020 Thêm định giá…	-	1kohm	± 10%	250mW	-	-	12.7mm	20.6mm	-800ppm/°C	Conductive Plastic	Turret	404 Series	26.92mm	12.7mm	8.51mm	-55°C	125°C
PTA6043-2015CPB103.	1857719 Bảng Tính RoHS	BOURNS POTENTIOMETER SLIDE 10KOHM 250mW ±20%	Each	1+US$2.070 10+US$1.760 25+US$1.570 50+US$1.500 100+US$1.420 Thêm định giá…	Low Profile	-	-	-	Linear	Through Hole	-	-	-	Carbon	PC Pin	-	-	-	-	-	50°C
PTA4544-2015DPA103	1688416 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Low Profile 10 kohm ± 20% 60 mW Log (Audio) Through Hole	Each	1+US$2.160 5+US$2.010 10+US$1.860 20+US$1.750 40+US$1.640 Thêm định giá…	Low Profile	10kohm	± 20%	60mW	Log (Audio)	Through Hole	45mm	15mm	-	Carbon	PC Pin	PTA Series	60mm	9mm	6.5mm	-10°C	50°C
RS4511150K	1191730 Bảng Tính RoHS	ALPS ALPINE Slide Potentiometer Standard Type 50 kohm ± 20% 125 mW Linear Through Hole	Each	1+US$3.360 50+US$2.100 100+US$1.910 250+US$1.720 500+US$1.620 Thêm định giá…	Standard Type	50kohm	± 20%	125mW	Linear	Through Hole	45mm	20mm	-	-	PC Pin	RS451 Series	60mm	8mm	7mm	-	-
PTA6043-2015DPB103	1688411 Bảng Tính RoHS	BOURNS Potentiometer Slide 60mm Travel 10 kohm 250 mW ± 20% PTA Series Linear	Each	1+US$2.320 5+US$2.130 10+US$1.940 20+US$1.830 40+US$1.710 Thêm định giá…	Low Profile	10kohm	± 20%	250mW	Linear	Through Hole	60mm	15mm	-	Carbon	PC Pin	PTA Series	75mm	9mm	6.5mm	-10°C	50°C
STRS30102K	1191729 Bảng Tính RoHS	ALPS ALPINE Potentiometer Slide 30mm Travel 50 kohm 100 mW ± 20% RS Series Linear	Each	1+US$2.510 5+US$1.590 10+US$1.450 25+US$1.310 50+US$1.230 Thêm định giá…	Standard Type	50kohm	± 20%	100mW	Linear	Through Hole	30mm	-	-	-	PC Pin	RS301 Series	45mm	8mm	7mm	-	-
PTA4543-2015DPB103	1688415 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Low Profile 10 kohm ± 20% 250 mW Linear Through Hole	Each	1+US$2.160 5+US$1.970 10+US$1.780 20+US$1.690 40+US$1.590 Thêm định giá…	Low Profile	10kohm	± 20%	250mW	Linear	Through Hole	45mm	15mm	-	Carbon	PC Pin	PTA Series	60mm	9mm	6.5mm	-10°C	50°C
PSL01-1082A-103B1	2838882 Bảng Tính RoHS	BOURNS Slide Potentiometer Motorized 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$48.060 5+US$43.970 10+US$39.870 25+US$34.920 50+US$33.700 Thêm định giá…	Motorized	10kohm	± 20%	500mW	Linear	Through Hole	100mm	8.2mm	-	-	Snap-in	PSL Series	157mm	15mm	25.6mm	-10°C	70°C
PTL01-15R0-103B1	2706336 Bảng Tính RoHS	BOURNS Potentiometer 10 kohm 200 mW ± 20% 100mm Travel PTL Series Linear	Each	1+US$6.350 50+US$4.640 100+US$4.090 250+US$4.080 500+US$4.060 Thêm định giá…	Standard Type with LED	10kohm	± 20%	200mW	Linear	Through Hole	100mm	15mm	-	Carbon	PC Pin	PTL Series	128mm	9.3mm	7mm	-10°C	55°C
PTB0143-2010BPB103	1688409 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Low Profile 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$6.330 5+US$5.750 10+US$5.160 20+US$4.900 40+US$4.630 Thêm định giá…	Low Profile	10kohm	± 20%	500mW	Linear	Through Hole	100mm	10mm	-	Carbon	PC Pin	PTB Series	128mm	15mm	8mm	-10°C	50°C
PTA2043-2010CIB254	2519654 Bảng Tính RoHS	BOURNS POT SLIDE 250KOHM 0.1W	Each	1+US$1.540 10+US$1.310 25+US$1.170 50+US$1.140 100+US$1.110 Thêm định giá…	-	-	± 20%	100mW	Linear	Through Hole	20mm	-	-	-	PC Pin	PTA Series	-	-	-	-	50°C
PTB6043-2010BPB103	1688410 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Low Profile 10 kohm ± 20% 250 mW Linear Through Hole	Each	1+US$5.590 5+US$5.120 10+US$4.650 20+US$4.370 40+US$4.090 Thêm định giá…	Low Profile	10kohm	± 20%	250mW	Linear	Through Hole	60mm	10mm	-	Carbon	PC Pin	PTB Series	88mm	15mm	8mm	-10°C	50°C
PTB6044-2010BPA103	1688413 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Low Profile 10 kohm ± 20% 125 mW Log (Audio) Through Hole	Each	1+US$5.690 5+US$5.220 10+US$4.750 20+US$4.460 40+US$4.160 Thêm định giá…	Low Profile	10kohm	± 20%	125mW	Log (Audio)	Through Hole	60mm	10mm	-	Carbon	PC Pin	PTB Series	88mm	15mm	8mm	-10°C	50°C
PTA2043-2015CPB103.	2519588 Bảng Tính RoHS	BOURNS POT SLIDE 10KOHM 0.1W	Each	1+US$1.540 10+US$1.310 25+US$1.170 50+US$1.130 100+US$1.090 Thêm định giá…	Low Profile	10kohm	-	-	Linear	-	20mm	-	-	Carbon	PC Pin	-	35mm	-	-	-	-
PTA3043-2010CIB103.	2519655 Bảng Tính RoHS	BOURNS POT SLIDE 10KOHM 0.2W	Each	1+US$1.770 10+US$1.500 25+US$1.340 50+US$1.300 100+US$1.260 Thêm định giá…	-	-	-	200mW	Linear	-	-	10mm	-	Carbon	-	-	45mm	9mm	-	-10°C	50°C
PTL30-15G1-103B1	2469523 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Standard Type with LED 10 kohm ± 20% 100 mW Linear Through Hole	Each	1+US$2.510 50+US$1.820 100+US$1.650 250+US$1.530 500+US$1.510 Thêm định giá…	Standard Type with LED	10kohm	± 20%	100mW	Linear	Through Hole	30mm	15mm	-	Carbon	PC Pin	PTL Series	45mm	9mm	7mm	-10°C	55°C
PSL60-1082A-103B1	2838883 Bảng Tính RoHS	BOURNS Slide Potentiometer Motorized 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$47.060 5+US$43.050 10+US$39.040 25+US$36.220 50+US$34.030 Thêm định giá…	Motorized	10kohm	± 20%	500mW	Linear	Through Hole	60mm	8.2mm	-	-	Snap-in	PSL Series	117mm	15mm	25.6mm	-10°C	70°C
PSM60-082A-103B2	2530215 Bảng Tính RoHS	BOURNS Slide Potentiometer Slide Motorized 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$43.280 5+US$37.960 10+US$34.020 20+US$32.040 40+US$30.640 Thêm định giá…	Motorized	10kohm	± 20%	500mW	Linear	Through Hole	60mm	8.2mm	-	Carbon	Snap-in	PSM Series	112mm	13mm	35mm	-10°C	55°C
PSP01-082A-103B2	2706334 Bảng Tính RoHS	BOURNS Slide Potentiometer Motorized 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$65.580 5+US$57.520 10+US$51.560 25+US$48.550 50+US$46.430 Thêm định giá…	Motorized	10kohm	± 20%	500mW	Linear	Through Hole	100mm	8.2mm	-	-	Snap-in	PSP Series	157mm	14mm	44.4mm	-10°C	70°C
PTB0143-2010BPB103.	1857456 Bảng Tính RoHS	BOURNS POTENTIOMETER SLIDE 10KOHM 500mW 20%	Each	1+US$6.330 2+US$6.040 3+US$5.750 5+US$5.460 10+US$5.160 Thêm định giá…	Low Profile	10kohm	± 20%	500mW	Linear	Through Hole	100mm	10mm	-	Carbon	PC Pin	PTB Series	128mm	15mm	8mm	-10°C	60°C
PTA4543-2015DPB103.	1857341 Bảng Tính RoHS	BOURNS POTENTIOMETER SLIDE 10KOHM 250mW 20%	Each	1+US$2.160 10+US$1.780 100+US$1.400 500+US$1.200 1000+US$1.170 Thêm định giá…	Low Profile	10kohm	± 20%	250mW	Linear	Through Hole	45mm	15mm	-	Carbon	PC Pin	PTA Series	60mm	9mm	6.5mm	-10°C	50°C
RS60N11	1191712 Bảng Tính RoHS	ALPS ALPINE Slide Potentiometer Standard Type 10 kohm ± 20% Log (Audio) Through Hole	Each	1+US$9.490 3+US$6.820	Standard Type	10kohm	± 20%	-	Log (Audio)	Through Hole	60mm	8.2mm	-	-	PC Pin	RS60N Series	88mm	16mm	8mm	-10°C	60°C
PTL20-15R0-103B1	5002522 Bảng Tính RoHS	BOURNS Slide Potentiometer Standard Type with LED 10 kohm ± 20% 50 mW Linear Surface Mount	Each	1+US$2.610 10+US$2.290 50+US$2.060 100+US$1.940 200+US$1.850 Thêm định giá…	Standard Type with LED	10kohm	± 20%	50mW	Linear	Surface Mount	20mm	15mm	-	Carbon	PC Pin	PTL Series	35mm	9mm	22mm	-10°C	55°C
PSM01-081A-103B2	5002657 Bảng Tính RoHS	BOURNS Slide Potentiometer Motorized 10 kohm ± 20% 500 mW Linear Through Hole	Each	1+US$27.560 5+US$24.170 10+US$21.670 20+US$20.400 40+US$19.510 Thêm định giá…	Motorized	10kohm	± 20%	500mW	Linear	Through Hole	100mm	8.2mm	-	Carbon	PC Pin	PSM Series	152mm	13mm	35mm	-10°C	55°C
