Hình ảnh chỉ mang tính minh họa. Vui lòng xem phần mô tả sản phẩm.
Nhà Sản XuấtRENESAS
Mã Số Linh Kiện Nhà Sản XuấtCCE4503-EVAL-V1
Mã Đặt Hàng4099493
Phạm vi sản phẩmTUK SGACK902S Keystone Coupler
Bảng Dữ Liệu Kỹ Thuật
Ngưng sản xuất
Thông Tin Sản Phẩm
Nhà Sản XuấtRENESAS
Mã Số Linh Kiện Nhà Sản XuấtCCE4503-EVAL-V1
Mã Đặt Hàng4099493
Phạm vi sản phẩmTUK SGACK902S Keystone Coupler
Bảng Dữ Liệu Kỹ Thuật
Kit Application TypeInterface
Application Sub TypeIO-Link Transceiver
Silicon ManufacturerRenesas
Silicon Core NumberCCE4503
Product RangeTUK SGACK902S Keystone Coupler
Kit ContentsEvaluation Board CCE4503
SVHCNo SVHC (14-Jun-2023)
Tổng Quan Sản Phẩm
CCE4503-EVAL-V1 evaluation board is designed to evaluate and demonstrate the CCE4503 IO-Link device IC. The CCE4503 is an easy-to-use device side IO-Link compliant transceiver IC. It combines IO-Link compliant communication capability with advanced protection circuitry and additional features while keeping the application small and simple.
- ARM cortex-M3 microcontroller
- Programmable via SWD
- Reset Button
- Status LED indicator
- 8 Kbit EEPROM
- Additional on-board protection circuitry
- All pins accessible via pin-headers for microcontroller and IO-link device IC
- CCE4503 IO-link device IC
- M12 connector + terminal blocks
- Three on-board sensors: temperature sensor, colour sensor, proximity sensor / switch
Thông số kỹ thuật
Kit Application Type
Interface
Silicon Manufacturer
Renesas
Product Range
TUK SGACK902S Keystone Coupler
SVHC
No SVHC (14-Jun-2023)
Application Sub Type
IO-Link Transceiver
Silicon Core Number
CCE4503
Kit Contents
Evaluation Board CCE4503
Tài Liệu Kỹ Thuật (2)
Pháp Chế và Môi Trường
Nước xuất xứ:
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiệnNước xuất xứ:Taiwan
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiện
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiệnNước xuất xứ:Taiwan
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiện
Số Thuế Quan:85423990
US ECCN:EAR99
EU ECCN:NLR
Tuân thủ tiêu chuẩn RoHS:Có
RoHS
Tuân thủ tiêu chuẩn RoHS Phthalates:Có
RoHS
SVHC:No SVHC (14-Jun-2023)
Tải xuống Chứng Nhận Chất Lượng Sản Phẩm
Chứng Nhận Chất Lượng Sản Phẩm
Trọng lượng (kg):.0035
