10 Bạn có thể đặt trước hàng ngay bây giờ
Số Lượng | Giá |
---|---|
1+ | US$102.500 |
10+ | US$97.040 |
25+ | US$87.640 |
50+ | US$85.540 |
100+ | US$83.440 |
Thông Tin Sản Phẩm
Tổng Quan Sản Phẩm
The TEN 40-2412WIR is a high performance 40W DC/DC Converter Module featuring ultra wide 4:1 input voltage range of 9 to 36VDC with industry-standard footprint. Input voltages up to 160 VDC, excellent EMC characteristics and EN 50155 approval make this device the best choice for many demanding applications in railroad and transportation systems. Further standard features include 12VDC output voltage, remote ON/OFF, overvoltage protection, under-voltage lockout and short-circuit protection. Low input current characteristics at minimal load make this converter also the ideal solution for battery-operated systems.
- No minimum load required
- Output voltage adjustable
- Thermal shock and vibration resistant according EN 61373
- 91% Typical efficiency
- 24VDC Nominal input voltage
Ứng Dụng
Wireless, Communications & Networking, Automation & Process Control, Test & Measurement
Thông số kỹ thuật
ITE & Railway
4:1
1 Output
3.333A
-
1.5kV
Fixed
10.2mm
9V
TEN 40WIR Series
DIP
40W
12V
-
-
24V
25.4mm
50.8mm
36V
No SVHC (14-Jun-2023)
Tài Liệu Kỹ Thuật (3)
Sản Phẩm Liên Kết
Tìm Thấy 4 Sản Phẩm
Pháp Chế và Môi Trường
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiệnNước xuất xứ:Taiwan
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiện
RoHS
RoHS
Chứng Nhận Chất Lượng Sản Phẩm
