Bạn cần thêm?
| Số Lượng | Giá |
|---|---|
| 1+ | US$205.200 |
| 5+ | US$186.800 |
| 10+ | US$183.540 |
Thông Tin Sản Phẩm
| Nhà Sản Xuất | MEAN WELL |
|---|---|
| Mã Số Linh Kiện Nhà Sản Xuất | HLG-600H-24ASao chép |
| Thời gian giao hàng tiêu chuẩn của nhà sản xuất | 20 tuần |
| Mã Đặt Hàng | 2944114 |
| Phạm vi sản phẩm | HLG-600H |
| Bảng Dữ Liệu Kỹ Thuật | |
| Power Supply Applications | - |
| Output Power Max | 600W |
| Output Voltage Max | 24VDC |
| Output Current | 25A |
| LED Driver Mode | Constant Current, Constant Voltage |
| Input Voltage Min | 90V |
| Input Voltage Max | 305V |
| Product Range | HLG-600H |
| SVHC | No SVHC (04-Feb-2026) |
Tổng Quan Sản Phẩm
HLG-600H-24A is a HLG-600H series 600W AC/DC LED driver featuring the dual mode constant voltage and constant current output. The design of metal housing with class I and IP67/IP65 ingress protection level allows to fit both indoor and outdoor applications. This is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. It includes over current, short circuit, overvoltage, over temperature protection. Application includes LED high-bay lighting, parking space lighting, LED fishing lamp, LED greenhouse lighting. Approved by UL60950-1, UL8750, CSA C22.2 No. 250.13-12, ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, IP65 or IP67, J61347-1, J61347-2-13, GB19510.1, GB19510.14, EAC TP TC 004, AS/NZS 60950.1(by CB), KC61347-1, KC61347-2-13.
- Input voltage range from 90 to 305VAC, 127 to 431VDC, output DC voltage is 24V
- Output rated current is 25A, output rated power is 600W, typical efficiency is 95%(230VAC, 277VAC)
- IP65 IP level, Io and Vo output adjustable via potentiometer
- Standby power consumption <lt/>0.5W at remote off
- Function options output adjustable via potentiometer, 3 in 1 dimming
- Typical lifetime <gt/> 62000 hours
- 7 years warranty
- Working temperature range from -40 to +90°C
- Dimension is (L x W x H) 280 x 144 x 48.5mm
Thông số kỹ thuật
| Power Supply Applications | - |
|---|---|
| Output Voltage Max | 24VDC |
| LED Driver Mode | Constant Current, Constant Voltage |
| Input Voltage Max | 305V |
| SVHC | No SVHC (04-Feb-2026) |
| Output Power Max | 600W |
|---|---|
| Output Current | 25A |
| Input Voltage Min | 90V |
| Product Range | HLG-600H |
Tài Liệu Kỹ Thuật (1)
Pháp Chế và Môi Trường
| Nước xuất xứ: Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiệnNước xuất xứ: | China Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiện |
|---|---|
| Số Thuế Quan: | 85044095 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| Tuân thủ tiêu chuẩn RoHS: | Có RoHS |
| Tuân thủ tiêu chuẩn RoHS Phthalates: | Có RoHS |
| SVHC: | No SVHC (04-Feb-2026) |
| Tải xuống Chứng Nhận Chất Lượng Sản Phẩm | Chứng Nhận Chất Lượng Sản Phẩm |
| Trọng lượng (kg): | 3.9 |
