Số Lượng | Giá |
---|---|
1+ | US$4.590 |
10+ | US$4.020 |
25+ | US$3.330 |
50+ | US$2.990 |
100+ | US$2.760 |
500+ | US$2.570 |
1000+ | US$2.450 |
Thông Tin Sản Phẩm
Tổng Quan Sản Phẩm
The MK03-1A66B-500W is a 15mm cylindrical Reed Sensor with 1 form-A contact. The sensor is magnetically operated reed proximity switches in a cylindrical case with an interconnect cable. The cable-cut length with 5mm of wire stripped and tinned termination. The sensor should be mounted on a fixed surface with the actuating magnet on the moving surface. Introduction or removal of the magnetic field determines the closing and opening of the reed switch. Suitable for position and limit switch, pneumatic or hydraulic actuator position Indication and end travel limit switch. Door and window contacts, security system applications. Level sensors use with magnetic floats for water level detection in coffee makers, washing machines or dishwashers.
- High power switches
- 66 Switch model
- 10 to 15 Pull-in AT magnetic sensitivity
- 500mm Cable length
Ứng Dụng
Industrial, Sensing & Instrumentation, Security, Consumer Electronics
Thông số kỹ thuật
Cylindrical Reed Sensor
15mm
250mA
85°C
15mm
-
-20°C
MK03 Series
Tài Liệu Kỹ Thuật (1)
Pháp Chế và Môi Trường
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiệnNước xuất xứ:China
Quốc gia nơi quy trình sản xuất quan trọng cuối cùng được thực hiện
RoHS
RoHS
Chứng Nhận Chất Lượng Sản Phẩm
